Peeled Split Mung Bean Color Sorter with 5400 Pixel CCD

Peeled Split Mung Bean Color Sorter with 5400 Pixel CCD

Product Details:

Place of Origin: Anhui China
Brand Name: DREAM PLUS
Certification: CE、SGS、ISO9001
Model Number: JM8

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Package
Delivery Time: 15-20 Working Days
Payment Terms: L/C, T/T
Supply Ability: 200 Set/Sets per Month
Get Best Price Contact Now

Detail Information

Model: 6SXM-512JM1 Chute: 8
Channel: 512 Capacity(t/h): 6-8
Carryover(bad:good): 12.5:1 Voltage(v/hz): 220/50
Weight(kg): 1800 Dimension(mm): 3152*1620*2040
Warranty: 1 Year
High Light:

Mung Bean Sorting Machine

,

Peeled Bean Color Sorter

,

8 Chute Bean Sorting Machine

Product Description

Peeled Split Mung Bean Sorting Color Sorter Machine

/Products Features/

The Newest Tech Innovation Beans Color Sorter for Various Beans Sorting

* Optical Sorting technolgoy With High Resolution 5400 Pixel CCD Camera,High Reliability And Long Life LED Light Source;

*With Efficient And Stable Software System, Intelligent Algorism, User Friendly Interface;

*With Better Sorting Accuracy, Lower Carryover, And Bigger Production Capacity for Coffee Beans sorting, Black Beans sorting etc;

*SOC Platform To Realize Stable, Reliable, Ultra-Fast Mass Data Processing;

*colour sorter Image capturing&Auto Intelligent sorting sytem with hundred programs can be applied for various beans sorting;

* China Grotech provide Remote Debugging, Diagnosing And Maintenance. Four Core Technologies To Ensure Your Operations



Peeled Split Mung Bean Color Sorter with 5400 Pixel CCD 0Peeled Split Mung Bean Color Sorter with 5400 Pixel CCD 1



Technical Parameter



Model 6SXM-512JM8
Output(T/h) 6~8
Carryover Rate(Bad:Good) >12.5:1
Sorting Accuracy(%) ≥99.99
Voltage (V/Hz) 220V 50HZ
Power Supply(Kw) ≤4.6
Pressure(Mpa) 0.5-0.8
Weight(Kg) 1800(±5%)
Diamension(mm) 3152*1620*2040



Sorting Material

Peeled Split Mung Bean Color Sorter with 5400 Pixel CCD 2

Technical Features



1. High reliability Our rice color sorter is equipped with cooling system for longer service life and higher stability. Reliable mechanical structure design, simple and effective electrical and optical system, and optimized system structure greatly improve the reliability of the machine.



2. Advanced image acquisition and processing system Our rice colour sorter uses high speed linear array CCD image sensor (2048 pixels) and high accuracy lens to realize image acquisition, which can detect 0.04mm2 heterochromatic regions. A specialized image processing system is used for high speed processing of spectral parameters and shape characteristics.



3. Intelligent image processing algorithm A intelligent algorithm based on color and shape is adopted, and special processing for yellows, stained, pinpoint blackheads etc. is carried out, thus increasing the accuracy of sorting.



4. High quality ejector.Our rice color sorter employs imported ejector for accurate, effective material rejection and long service life.



5. High rejection rate Advanced image acquisition system, intelligent image processing algorithm, coupled with quality nozzle system, result in high rejection rate.



6. Simple operation Simple optical system, precise auto calibration system and user-friendly man-machine interface greatly simplify the machine debugging process and ensure ease of operation.
