Product Details:

Place of Origin: Hefei,China
Brand Name: Dream Plus
Model Number: JM1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Wooden Package
Delivery Time: 15-20 Working Days
Payment Terms: T/T, L/C
Get Best Price Contact Now

Detail Information

Model: 6SXM-64J1 Chute: 1
Channel: 64 Capcity(t/h): 0.6-1
Carryover(bad:good): 12.5:1 Voltage(v/hz): 220/50
Power(kw): ≤1.5 Weight(kg): 350
Dimension(mm): 955*1630*1550 Warranty: 1 Year
Color: White
High Light:

One Chute Mini Color Sorter

,

Low Power Consumption Mini Color Sorter

,

Auto Computing Mini Color Sorter

Product Description

Long Life Mini Color Sorter Machine Low Power Consumption Automatic Computing

ABOUT US



Hefei Dream Plus Co., Ltd. is a high-tech enterprise specializing in the research and development, production, sales and technical services of agricultural, industrial intelligent sorting and pets medical equipment. Located in Hefei High-tech Development Zone, it has a modern standardized production workshop of 15,000 square meters and a registered capital of 50 million yuan.



The company has a research and development team with many years of experiences engaged in photoelectric recognition research, with rich practical experiences and strong research and development capabilities. Has now developed into a large-scale domestic manufacturer of intelligent sorting and testing equipment with a rich product range and multiple sorting applications



In the field of intelligent sorting, the company not only has professional laboratories, production and testing equipment and a complete intelligent sorting and testing product line, but also can provide personalized product customization services according to the actual needs of customerss, providing customers with a full range of intelligent sorting solutions.



The company’s main product is AI intelligent color sorter, X-ray machine, pets medical CT, etc., have been recognized by customers with excellent quality and high-quality service, and have established a global marketing network. In the future, Dream Plus will continue to develop the core technology of photoelectric recognition system and strive to become a high-tech service company in the field of intelligent sorting.

Auto Computing Mini Color Sorter Low Power Consumption 0

Dream Plus mini Color Sorter Machine , 96 channel, High Output , High Accuracy



JM Series Rice color sorter is the high-end product with remote control AI system.

  • Automatic Computing and Super Brain Intelligent Identification
  • Image Processing System
  • Intelligent Dust Cleaning System
  • Self Design High Frequency Ejectors
  • Low Temperature LED Light Source
  • Intelligent LED Control System
  • Remote Control System



Technical Specification:



Model 6SXM-64J1
Output(T/h) 0.5~1.0
Carryover Rate(Bad:Good) >10:1
Sorting Accuracy(%) ≥99.99
Voltage (V/Hz) 220V 50HZ
Power Supply(Kw) ≤1.5
Pressure(Mpa) 0.5-0.8
Weight(Kg) 350(±5%)
Diamension(mm) 955*1630*1550





Features



1. High reliability Our rice color sorter is equipped with cooling system for longer service life and higher stability. Reliable mechanical structure design, simple and effective electrical and optical system, and optimized system structure greatly improve the reliability of the machine.

2. Advanced image acquisition and processing system Our rice colour sorter uses high speed linear array CCD image sensor (5400 pixels) and high accuracy lens to realize image acquisition, which can detect 0.0025mm2 heterochromatic regions. A specialized image processing system is used for high speed processing of spectral parameters and shape characteristics.

3. Intelligent image processing algorithm A intelligent algorithm based on color and shape is adopted, and special processing for yellows, stained, pinpoint blackheads etc. is carried out, thus increasing the accuracy of sorting.

4. High quality ejector.Our rice color sorter employs imported ejector for accurate, effective material rejection and long service life.

5. High rejection rate Advanced image acquisition system, intelligent image processing algorithm, coupled with quality nozzle system, result in high rejection rate.

6. Simple operation Simple optical system, precise auto calibration system and user-friendly man-machine interface greatly simplify the machine debugging process and ensure ease of operation.

7. High flexibility, wide range of application Our color sorter is suitable for color sorting of different rice. Various optimal working modes are available for different rice.
