Smart Quinoa Color Sorter 640 Channel 5.0-6.0 T/H Capacity

Smart Quinoa Color Sorter 640 Channel 5.0-6.0 T/H Capacity

Product Details:

Place of Origin: Anhui China
Brand Name: DREAM PLUS
Certification: CE、SGS、ISO9001
Model Number: JM10

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Package
Delivery Time: 7-15 Working Days
Payment Terms: L/C, T/T
Supply Ability: 200 Set/Sets per Month
Get Best Price Contact Now

Detail Information

Model: 6SXM-640JM10 Chutes: 10
Channel: 640 Capacity(t/h): 5.0-6.0
Carryover(bad:good): 12.5:1 Voltage(v/hz): 220/50
Power(kw): ≤5.5 Weight(kg): 2200
Dimension: 3910*1620*2040
High Light:

5.0 T/H Grain Color Sorter


Smart Quinoa Color Sorter


6.0 T/H Grain Color Sorter

Product Description

Smart Quinoa Color Sorter,2-Year Warranty
Smart Quinoa Color Sorter is a new designed multi-purpose color sorter, which offers color selection work for sorting rice,millet,sunflower kernel,soybeans, corn, beans, peanuts,wheat, pepper, chickpeas tea, grains and cereals,plastic,ore,metal etc.
What kind of materials can our color sorter select:
Food materials:
Such as: Rice, Wheat, Corn, Soybean, Peanut, Sunflower seeds, Waltnut, Almond, Quinoa, Salt, Medlar, Pistachio, Kidney bean, Chili, Red bean, etc.
Plastic materials:
Such as: Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic, etc.

Note: the performance and parameters for the above color sorter are only taking the standard rice (impurity 2%), as an example, the specific index will vary with different material and impurity levels.


Smart Quinoa Color Sorter 640 Channel 5.0-6.0 T/H Capacity 0


Technical Parameter

Model 6SXM-640JM10
Output(T/h) 2.0-3.0
Carryover Rate(Bad:Good) >12.5:1
Sorting Accuracy(%) ≥99.99
Voltage (V/Hz) 220V 50HZ
Power Supply(Kw) ≤5.5
Pressure(Mpa) 0.5-0.8
Weight(Kg) 2200(±5%)
Diamension(mm) 3910*1620*2040


Sorting Material

Smart Quinoa Color Sorter 640 Channel 5.0-6.0 T/H Capacity 1

Technical Features
1. High reliability Our rice color sorter is equipped with cooling system for longer service life and higher stability. Reliable mechanical structure design, simple and effective electrical and optical system, and optimized system structure greatly improve the reliability of the machine.
2. Advanced image acquisition and processing system Our rice colour sorter uses high speed linear array CCD image sensor (5400 pixels) and high accuracy lens to realize image acquisition, which can detect 0.0025mm2 heterochromatic regions. A specialized image processing system is used for high speed processing of spectral parameters and shape characteristics.
3. Intelligent image processing algorithm A intelligent algorithm based on color and shape is adopted, and special processing for yellows, stained, pinpoint blackheads etc. is carried out, thus increasing the accuracy of sorting.
4. High quality ejector.Our rice color sorter employs imported ejector for accurate, effective material rejection and long service life.
5. High rejection rate Advanced image acquisition system, intelligent image processing algorithm, coupled with quality nozzle system, result in high rejection rate.
6. Simple operation Simple optical system, precise auto calibration system and user-friendly man-machine interface greatly simplify the machine debugging process and ensure ease of operation.
7. High flexibility, wide range of application Our color sorter is suitable for color sorting of different rice. Various optimal working modes are available for different rice.
