Chromatic Wheat Color Sorter 2 Chute 5400 Pixel 1 Year Warranty
Product Details:
| Place of Origin: | Anhui China |
| Brand Name: | DREAM PLUS |
| Certification: | CE、SGS、ISO9001 |
| Model Number: | JM2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Package |
| Delivery Time: | 7-15 Working Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 Set/Sets per Month |
|
Detail Information |
|||
| Model: | 6SXM-160JM2 | Chute: | 2 |
|---|---|---|---|
| Channel: | 160 | Warranty: | 1 Year |
| Capacity(t/h): | 0.5-1.0 | Carryover Rate(bad:good): | 12.5:1 |
| Power(kw): | ≤1.8 | Voltage(v/hz): | 220/50 |
| Weight(kg): | 600 | Dimension(mm): | 1330*1630*1550 |
| Highlight: | Chromatic Wheat Color Sorter,Wheat Color Sorter 5400 Pixel,Chromatic Wheat Sorter |
||
Product Description
2 Chute 5400 Pixel Chromatic Wheat Color Sorter Export to Europe
Wheat Colour Sorter Machine
We are counted amongst as the leading manufacturers, exporters and suppliers of excellent quality Wheat Color Sorter Machine that is excellent in performance. Offered sorter is highly admired for sorting application with complete accuracy. In order to meet the set industry norm, this sorter is precisely engineered by our diligent professionals by making use of quality assured components and modern technology. Also, this Wheat Color Sorter Machine can be availed from us in diverse specifications as per the client's requirement.
Technical Parameter
| Model | 6SXM-160JM2 |
| Output(T/h) | 0.5-1.0 |
| Carryover Rate(Bad:Good) | >12.5:1 |
| Sorting Accuracy(%) | ≥99.99 |
| Voltage (V/Hz) | 220V 50HZ |
| Power Supply(Kw) | ≤1.8 |
| Pressure(Mpa) | 0.5-0.8 |
| Weight(Kg) | 600(±5%) |
| Diamension(mm) | 1330*1630*1550 |
Sorting Material
Technical Features
1. High reliability Our rice color sorter is equipped with cooling system for longer service life and higher stability. Reliable mechanical structure design, simple and effective electrical and optical system, and optimized system structure greatly improve the reliability of the machine.
2. Advanced image acquisition and processing system Our rice colour sorter uses high speed linear array CCD image sensor (5400 pixels) and high accuracy lens to realize image acquisition, which can detect 0.0025mm2 heterochromatic regions. A specialized image processing system is used for high speed processing of spectral parameters and shape characteristics.
3. Intelligent image processing algorithm A intelligent algorithm based on color and shape is adopted, and special processing for yellows, stained, pinpoint blackheads etc. is carried out, thus increasing the accuracy of sorting.
4. High quality ejector.Our rice color sorter employs imported ejector for accurate, effective material rejection and long service life.
5. High rejection rate Advanced image acquisition system, intelligent image processing algorithm, coupled with quality nozzle system, result in high rejection rate.
6. Simple operation Simple optical system, precise auto calibration system and user-friendly man-machine interface greatly simplify the machine debugging process and ensure ease of operation.
